Effective Moment of Inertia of Beam-Slab Section under Lateral Load

  • Dr. Adnan Falih Ali College of Engineering-University of Baghdad, Iraq
  • Yasir Wisam Abduljaleel College of Engineering, AL-Iraqia University, Baghdad, Iraq
الكلمات المفتاحية: Two way slab, Moment of Inertia of Beam-Slab Section and Lateral Load


This study developed the modified equivalent frame method, using column elements and equivalent slab-beam elements for two-way slab systems under lateral loads. A detailed comparative study between the F.E analysis (which is based on the three dimensional full width of slab) and 3D frame analysis using different types of effective moment of inertia of beam-slab section. The purpose of this step is to choose an appropriate model of effective width of slab to represent the full width of slab under lateral loads. The dynamic analysis was done using finite element procedure provided by ETABS 2013.Parametric studies were carried out to evaluate the effects of several factors such as panel of slab aspect ratio, column aspect ratio, column to span ratio, irregularity in plan of buildings and height of buildings. Two heights of buildings were considered for those above mentioned factors, these are (45m and 75m).This study presents the modified beam model, which gives the effective moment inertia of slab-beam system under lateral load. The response of the proposed model gives a good result in comparison with F.E idealization with small error range from

  • (2-5)% for displacement and frequency.
  • (5-8)% for base shear and base moment.


[1] Allen, F. and Darvall, P. (1977) "Lateral Load Equivalent Frame" ACI Journal, No 74.32 the 14th world Conference on Earthquake Engineering, Beijing, China.
[2] ASCE 7 (2010) "Minimum Design Loads for Buildings and Other Structures".
[3] Fraser, D. J. (1983) "Elastic Analysis of Lateral Frames" ASCE Vol.109, No.6
[4] Gorossmon, J.S (1997)"Verification of Proposed Design Methodologies for Effective with of Slab in Slab-Column Frame" ACI Structural Journal; 94(2) PP. (181-191).
[5] Habeeb, N.Z.(2007) " 2D Idealization Scheme to Model 3D R.C. Buildings Subjected To Earthquake "M.Sc Thesis, College of Engineering University of Baghdad
[6] Kim, H.S. and Lee, D.G (2005) "Efficient analysis Of Flat Slab structures subjected to Lateral Loads" Engineering of structure, ELSEVIER
[7] Luo, Y.H. and Darrani, A.J. (1995)"Experimental Beam Model for Flat-Slab Building", Part I, Interior Connections " ACI Structural Journal 92(2), PP (250- 257).
[8] Newmark, N.M., and Hall, W.J. (1982) "Earthquake Spectra and Design" Engineering Research Institute, Berkeley, California
[9] Park Y.M., Han, S. W., and Kee, S.H. (2008) "A modified Equivalent Method for Lateral Load Analysis", Magazine of Concrete Research
[10] Pecknold, D.A (1975) "Slab Width For Equivalent Frame Analysis" ACI Journal
Proceeding 72(4), PP. 135-137.
[11] Penzein, J. and Watable (1975)"Characteristics of 3D Earthquake Ground Motion" Earthquake Engineering and Structural Dynamics, Vol. 3, PP 365-373.
[12] Vandevit, M.D., (1979)"Equivalent Frame Analysis for Lateral Load "ASEC Journal of Structural Division, Vol.105, No. ST10, PP. (1981-1997)
